SSEM – Solid State Electric Home & RV Meter, AC Kilowatt-Hour CL200 – 2S, 240V
M281C1P6H Midwest 200 Amp Manufactured Home Pedestal – Ring Type

R281C1P6H Midwest 200 Amp Manufactured Home Pedestal – Ringless style

$489.98

Availability: SHIPS IN | 6-8 weeks SKU: R281C1P6H Categories: ,

Download:
Product Spec Sheet – Download
Cut Sheet – Download

  • Add Meter
    • $
    • 35 $
Calculate shipping price

Please fill in the fields below with the shipping destination details in order to calculate the shipping cost.

Description

Product Description

Ringless, 200 Amp, 120/240 Volt, 1-Phase, NEMA 3R, Pedestal with Horn Bypass
The R281C1P6h is a Metered Service Entrance Equipment for mobile home and manufactured homes. Where electrical power enters a building or other source, the National Electrical Code (NEC) requires electrical distribution equipment rated as “Service Entrance.” Such service equipment usually consists of one main breaker disconnect or space for up to 6 main disconnects. Midwest models meet these NEC requirements and are UL listed as service entrance equipment.
This mobile home pedestal by Midwest is a 200 amp pedestal manufactured for direct buyr.  The service entrance pedestal is rated with a 200 amp main breaker that is included. It has a 120/240v ring-type meter socket (meter not included) and is series wired with loop-fed lugs and 4 additional breaker spaces.

Product Specifications

UPC: 784567588101
Enclosure:  NEMA 3R
Approval:  UL
Additional Information:  Applicable Standard NEMA, NEC; Voltage Rating 120/240 V; Cabinet Dimension 9-5/16 Inch W x 4-3/4 Inch D x 30-1/4 Inch H
Catalog Number:  R281C1P6H
Type:  Metered Ringless – Horn Bypass
Current Rating:  200 Ampere
Circuit Configuration:  1-Phase
Wire Size:  6 AWG to 350 KCMIL (Copper/Aluminum, (Line), 12 to 2 AWG (Copper/Aluminum, Ground)
Material:  G90 Galvanized Steel
Finish:  Durable Polyester Powder Coated
Mounting:  Pedestal
CATALOG DESCRIPTION:  NATIONAL ELECTRIC CODE REQUIRES ELECTRICAL DISTRIBUTION EQUIPMENT TO BE RATED AS SERVICE ENTRANCE, WHEREVER ELECTRICAL POWER ENTERS A BUILDING OR OTHER STRUCTURE. SERVICE ENTRANCE PRODUCTS ARE TYPICALLY UTILIZED ON SINGLE-FAMILY RESIDENCES AND MOBILE HOMES. MIDWEST ELECTRIC OFFERS A BROAD RANGE OF SURFACE MOUNT AND PEDESTAL UNITS, FACTORY ASSEMBLED AND WIRED. PEDESTAL UNITS COME STANDARD WITH LOOP FEED LUGS TO REDUCE INSTALLATION TIME AND LABOR EXPENSE. SERVICE ENTRANCE EQUIPMENT IS MADE OF HEAVY, GALVANIZED G-90 STEEL, PREVENTING CORROSION AND FADING.
Category:  Metered Power Outlet Pedestals
Full Technical Description:  Metered Ringless Type; G90 Galvanized Steel Material; Durable Polyester Powder Coated Finish; 6 AWG to 350 kcmil (Copper/Aluminum, (Line), 12 to 2 AWG (Copper/Aluminum, Ground) Wire Size; UL Approval; Pedestal Mounting; NEMA 3R Enclosure; 200 Ampere Current Rating; 1-Phase Circuit Configuration; Applicable Standard NEMA, NEC; Voltage Rating 120/240 V; Cabinet Dimension 9-5/16 Inch W X 4-3/4 Inch D X 30-1/4 Inch H
Manufacturer:  Midwest Electric Products, Inc.
Manufacturer Brand:  Midwest Electric Products, Inc.
Product Description:  MIDWEST R281C1P6H 200A HEADPOST METERED
Sub-Category:  Outdoor Pedestal Mount Power Outlet Panel
UNSPSC:  39121102
UPC 12 Digit:  784567588101
Unique Product Key:  6006100



Additional information

Weight 40 lbs
